Contemporary House Plan

PLN-J1004 Front1_edited_edited.jpg



PLN-J1004 Plan_edited_edited.jpg

Metropolitan (nickname)

Plan # PLN-J1004

Plan #PLN-J1004 Specifications

Overall size            1887 sq/ft

Overall Dimensions 48 ft W x 64 ft D

Roof Pitch              4-1/2-12, 3-12

Exterior Walls         2x6

3 Bedrooms

1 Office

2 Bathrooms

Double car garage (with work shop area)



The Metropolitan is a Contemporary home that speaks modern from the Exterior with its Asymmetrical Angular shed roof design to its interior with its tall vaulted ceiling Entry and Great room.  As you enter this home you step into a massive Entryway with 17 ft high one way vaulted ceiling with transom windows up high that let the natural light in. To your right you will find a dedicated office (or multipurpose room) with lots of windows again to create a bright work area. As you continue down the entry hall you pass the u-shaped stair with glass railing followed by the modern open concept kitchen and dinning area. This wide open feel is thanks to a hidden beam recessed into the ceiling. The only support is hidden in the feature wall between the kitchen and dinning with contemporary louver design so as to not spoil the open views. The Great room is to the left of the kitchen with massive high one-way vaulted ceiling, featuring a tall fireplace with horizontal shiplap accenting and is flanked by double high windows. There are also transom windows at the tall side of the vault. The garage entry accesses the dedicated laundry room and there is ample closet space both here and and the front entry. Down the hallway there are three generous bedrooms including the primary with ensuite bath that has a double sink vanity and shower. The full main bath has a shower/tub combo and large single vanity. The extra large double car garage has room for workshop / storage area.


Main Floor Details

Front Entry                    7'-8" x 29'-8"

Great Room                   16'-1 x 14'-7"

Kitchen                         12'-8" x 12'-4"

Dining Rm                     12'-0" x 10'-7"

Main Bedroom               15'-6" x 11'-8"

(with walk-in closet)

2 Secondary Bedrooms

Dedicated Office            12'-0" x 12'-0"

Main Bath                     8'-6" x 5'-7"

Ensuite Bath with shower   6'-4" x 5'-4"

Laundry Room               5'-0" x 8'-9"

Covered Deck                11'-8" x 28'-8"

(accessible from Dining rm + Primary Bedroom)

2 Car Garage                24' x 28'

Unfinished full basement for future development

     (Finished basement floor plan available upon request)



* Note that while every effort is made to ensure the Descriptions above are as accurate as possible, they are still subject to data entry error. KQW&D makes no guaranty as to accuracy.


PDF Plan Set (digital Document) includes:

-Cover Page with Isometric views

-Main Level floor plan (inc. electrical)

-Foundation plan

-Sections / Roof planes / Stair detail plan

-Elevations plan


*PDF's are scaled for print to 24" x 36" Sheets. You may print at alternate sizes but be aware they will not be to the indicated scale.


When you press the buy plan button below you will be able to pick from these options:


Base PDF Plan Set Price - $ 795.00

(Digital image file -Does not include printed plans)

(Includes License to print plans for the construction of One dwelling)


Plan Options


Option - Reverse Plan - $ 75.00


Kitchen Plan Inc. Island - $ 100.00


* All priced are in Canadian Dollars (CAD) and include GST. For orders from all Canadian Provinces the buyer is responsible to pay PST directly to their Province (if applicable)
